Alert

This module contains the classes that define and implement the Alert interface API. More...

Collaboration diagram for Alert:

Data Structures
struct	HF::Interfaces::Alert::Message
	Payload for the Status command. More...
struct	HF::Interfaces::Alert::State
	Helper class to handle the State attribute for the Alert interface. More...
struct	HF::Interfaces::Alert::Enable
	Helper class to handle the Enabled attribute for the Alert interface. More...
struct	HF::Interfaces::Alert::Base
	Alert Interface : Parent. More...
class	HF::Interfaces::Alert::Server
	Alert Interface : Server side implementation. More...
struct	HF::Interfaces::Alert::Client
	Alert Interface : Client side implementation. More...

Enumerations
enum	HF::Interfaces::Alert::CMD { HF::Interfaces::Alert::STATUS_CMD = 0x01 }
	Command IDs. More...
enum	HF::Interfaces::Alert::Attributes { HF::Interfaces::Alert::STATE_ATTR = 0x01, HF::Interfaces::Alert::ENABLE_ATTR = 0x02 }
	Attributes. More...

Functions
HF::Attributes::IAttribute *	HF::Interfaces::create_attribute (HF::Interfaces::Alert::Server *server, uint8_t uid)
	Create an attribute object that can hold the attribute with the given uid. More...
HF::Attributes::IAttribute *	HF::Interfaces::Alert::create_attribute (uint8_t uid)
	Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::Alert::Server *,uint8_t) More...
std::ostream &	operator<< (std::ostream &stream, const HF::Interfaces::Alert::CMD command)
	Convert the given command into a string and write it to the given stream. More...
std::ostream &	operator<< (std::ostream &stream, const HF::Interfaces::Alert::Attributes attribute)
	Convert the given attribute into a string and write it to the given stream. More...

Detailed Description

This module contains the classes that define and implement the Alert interface API.

Enumeration Type Documentation

Attributes

enum HF::Interfaces::Alert::Attributes

Attributes.

Enumerator
STATE_ATTR	State attribute UID.
ENABLE_ATTR	Enable attribute UID.

Definition at line 76 of file alert.h.

         {
            STATE_ATTR    = 0x01,
            ENABLE_ATTR   = 0x02,
            __LAST_ATTR__ = ENABLE_ATTR,
         } Attributes;

CMD

enum HF::Interfaces::Alert::CMD

Command IDs.

Enumerator
STATUS_CMD	Alert Status Command ID.

Definition at line 69 of file alert.h.

         {
            STATUS_CMD   = 0x01,
            __LAST_CMD__ = STATUS_CMD
         } CMD;

Function Documentation

create_attribute() [1/2]

HF::Attributes::IAttribute* HF::Interfaces::create_attribute	(	HF::Interfaces::Alert::Server *	server,
		uint8_t	uid
	)

Create an attribute object that can hold the attribute with the given uid.

If server is not equal to nullptr then initialize it with the current value.

Parameters

[in]	server	pointer to the object to read the current value from.
[in]	uid	attribute's UID to create the attribute object for.

Return values

pointer	to an attribute object
<tt>nullptr</tt>	if the attribute UID does not exist.

Referenced by HF::Interfaces::SimpleHumidity::Server::attribute(), HF::Interfaces::OnOff::Server::attribute(), HF::Interfaces::SimpleTemperature::Server::attribute(), HF::Interfaces::Alert::Server::attribute(), HF::Interfaces::LevelControl::Server::attribute(), HF::Interfaces::SimpleThermostat::Server::attribute(), HF::Interfaces::SimpleTemperature::create_attribute(), and HF::Interfaces::SimpleVisualEffects::create_attribute().

Here is the caller graph for this function:

create_attribute() [2/2]

HF::Attributes::IAttribute* HF::Interfaces::Alert::create_attribute ( uint8_t  uid )

inline

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::Alert::Server *,uint8_t)

See also

HF::Interfaces::create_attribute (HF::Interfaces::Alert::Server *,uint8_t)

Parameters

[in]

uid

attribute UID to create the attribute object for.

Return values

pointer	to an attribute object
<tt>nullptr</tt>	if the attribute UID does not exist.

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::Alert::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::Scheduling::Weekly::IServer *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::Time::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::SUOTA::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::RSSI::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::GroupTable::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid.

Create an attribute object that can hold the attribute with the given uid. (HF::Core::Scheduling::Event::IServer *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::DeviceManagement::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::DeviceInformation::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::BindManagement::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::BatchProgramManagement::IServer *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::AttributeReporting::Server *,uint8_t)

See also

HF::Interfaces::create_attribute (HF::Interfaces::SimpleHumidity::Server *,uint8_t)

Parameters

[in]

uid

attribute UID to create the attribute object for.

Returns

pointer to an attribute object or nullptr if the attribute UID does not exist.

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::Alert::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::Scheduling::Weekly::IServer *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::Time::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::SUOTA::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Interfaces::RSSI::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::GroupTable::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid.

Create an attribute object that can hold the attribute with the given uid. (HF::Core::Scheduling::Event::IServer *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::DeviceManagement::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::DeviceInformation::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::BindManagement::Server *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::BatchProgramManagement::IServer *,uint8_t)

Create an attribute object that can hold the attribute with the given uid. (HF::Core::AttributeReporting::Server *,uint8_t)

See also

HF::Interfaces::create_attribute (HF::Interfaces::SimpleTemperature::Server *,uint8_t)

Parameters

[in]

uid

attribute UID to create the attribute object for.

Return values

pointer	to an attribute object
<tt>nullptr</tt>	if the attribute UID does not exist.

Definition at line 108 of file simple_humidity.h.

         {
            return Interfaces::create_attribute(static_cast<SimpleHumidity::Server *>(nullptr),
                                                uid);
         }

operator<<() [1/2]

std::ostream& operator<<	(	std::ostream &	stream,
		const HF::Interfaces::Alert::CMD	command
	)

Convert the given command into a string and write it to the given stream.

Parameters

[in]	stream	out stream to write the string to.
[in]	command	role value to convert to a string.

Returns

stream

operator<<() [2/2]

std::ostream& operator<<	(	std::ostream &	stream,
		const HF::Interfaces::Alert::Attributes	attribute
	)

Convert the given attribute into a string and write it to the given stream.

Parameters

[in]	stream	out stream to write the string to.
[in]	attribute	attribute value to convert to a string.

Returns

stream
