HF::Protocol::Message::Interface Struct Reference

Interface Address. More...

#include <protocol.h>

Inheritance diagram for HF::Protocol::Message::Interface:

Collaboration diagram for HF::Protocol::Message::Interface:

Public Member Functions
	Interface (uint16_t uid=0, uint8_t role=0, uint8_t member=0)
	Constructor. More...
uint16_t	size () const
	Number bytes needed to serialize the message. More...
uint16_t	pack (Common::ByteArray &array, uint16_t offset=0) const
	Write the object on to a ByteArray so it can be sent over the network. More...
uint16_t	unpack (const Common::ByteArray &array, uint16_t offset=0)
	Read a message from a ByteArray. More...
Public Member Functions inherited from HF::Common::Interface
	Interface (uint16_t id=0, uint8_t role=0)
	Constructor. More...
uint16_t	size () const
	Number bytes needed to serialize the message. More...
uint16_t	pack (Common::ByteArray &array, uint16_t offset=0) const
	Write the object on to a ByteArray so it can be sent over the network. More...
uint16_t	unpack (const Common::ByteArray &array, uint16_t offset=0)
	Read a message from a ByteArray. More...

Data Fields
uint8_t	member
	Interface destination member. More...
Data Fields inherited from HF::Common::Interface
uint16_t	role: 1
	Interface role : Server or Client. More...
uint16_t	id: 15
	Identifier of the interface. More...

Static Public Attributes
static const uint16_t	min_size
	Minimum pack/unpack required data size.
Static Public Attributes inherited from HF::Common::Interface
static constexpr uint16_t	min_size = sizeof(uint16_t)
	Minimum pack/unpack required data size.

Detailed Description

Interface Address.

Definition at line 93 of file protocol.h.

Constructor & Destructor Documentation

Interface()

HF::Protocol::Message::Interface::Interface ( uint16_t  uid = 0, uint8_t  role = 0, uint8_t  member = 0  )

inline

Constructor.

Parameters

[in]	uid	interface UID.
[in]	role	interface role.
[in]	member	interface member.

Definition at line 108 of file protocol.h.

                                                                             :
               Common::Interface(uid, role), member(member)
            {}

Member Function Documentation

pack()

uint16_t HF::Protocol::Message::Interface::pack	(	Common::ByteArray &	array,
		uint16_t	offset = 0
	)		const

Write the object on to a ByteArray so it can be sent over the network.

The buffer passed in MUST have enough size to hold the serialized object, e.g.,

Serializable obj;
ByteArray payload(obj.size());
obj.pack(payload);

Parameters

[in,out]	array	ByteArray reference to write the object to.
[in]	offset	offset to start writing to.

Returns

the number of bytes written.

size()

uint16_t HF::Protocol::Message::Interface::size

(

)

const

Number bytes needed to serialize the message.

Returns

number of bytes the message requires to be serialized.

unpack()

uint16_t HF::Protocol::Message::Interface::unpack	(	const Common::ByteArray &	array,
		uint16_t	offset = 0
	)

Read a message from a ByteArray.

Parameters

[in]	array	ByteArray reference to read the message from.
[in]	offset	offset to start reading from.

Returns

the number of bytes read.

Field Documentation

member

uint8_t HF::Protocol::Message::Interface::member

Interface destination member.

Definition at line 99 of file protocol.h.

Referenced by HF::Core::SessionManagement::AbstractClient::get_entries(), HF::Interfaces::SimpleHumidity::Client::read(), HF::Interfaces::SimpleTemperature::Client::read(), HF::Interfaces::SimpleLightSensor::Client::read(), and HF::Core::SessionManagement::AbstractClient::request().

---

The documentation for this struct was generated from the following file:

• protocol.h
