HF::Core::Scheduling::Weekly::Server< _Entries > Struct Template Reference

Scheduling Service : Server side implementation. More...

#include <weekly_scheduling.h>

Inheritance diagram for HF::Core::Scheduling::Weekly::Server< _Entries >:

Collaboration diagram for HF::Core::Scheduling::Weekly::Server< _Entries >:

Public Member Functions
	Server (Unit0 &unit)
	Constructor. More...
_Entries &	entries () const
	Get a reference to the current object implementing the persistence API, for the device information. More...
Public Member Functions inherited from HF::Core::Scheduling::Weekly::IServer
virtual Common::Result	define_event (const Protocol::Packet &packet, Scheduling::Entry< Day > &msg)
	Callback that is called when a Scheduling::DEFINE_EVENT_CMD, is received. More...
virtual Common::Result	update_event_status (const Protocol::Packet &packet, const UpdateStatus &msg)
	Callback that is called when a Scheduling::UPDATE_STATUS_CMD, is received. More...
virtual Common::Result	get_event_entry (const Protocol::Packet &packet, const GetEntry &msg)
	Callback that is called when a Scheduling::GET_ENTRY_CMD, is received. More...
virtual Common::Result	delete_event (const Protocol::Packet &packet, const DeleteEvent &msg)
	Callback that is called when a Scheduling::DELETE_CMD, is received. More...
virtual Common::Result	delete_all_events (const Protocol::Packet &packet)
	Callback that is called when a Scheduling::DELETE_ALL_CMD, is received. More...
	IServer (Unit0 &unit)
	Constructor.
virtual	~IServer ()
	Destructor.
Common::Pointer< Entry >	entry (const uint8_t id) const
	Get the Weekly Scheduling entry given by id. More...
uint8_t	next_id () const
	Return next available id for event. More...
Public Member Functions inherited from HF::Core::Service< _ITF, _Parent >
uint16_t	uid () const
	This method returns the interface UID. More...

Additional Inherited Members
Protected Member Functions inherited from HF::Core::Scheduling::Base< _ITF, _Parent >
	Base (Unit0 &unit)
	Constructor.
Protected Member Functions inherited from HF::Core::Service< _ITF, _Parent >
	Service (Unit0 &unit)
	Constructor. More...
bool	check_uid (uint16_t uid) const
	Check if the given uid value matches the service's UID value. More...

Detailed Description

template<typename _Entries>
struct HF::Core::Scheduling::Weekly::Server< _Entries >

Scheduling Service : Server side implementation.

This class provides the server side of the Scheduling interface.

Definition at line 502 of file weekly_scheduling.h.

Constructor & Destructor Documentation

Server()

template<typename _Entries >

HF::Core::Scheduling::Weekly::Server< _Entries >::Server ( Unit0 &  unit )

inline

Constructor.

Parameters

[in]

unit

reference to the unit containing this service.

Definition at line 518 of file weekly_scheduling.h.

                                  : IServer(unit)
               {}

Member Function Documentation

entries()

template<typename _Entries >

_Entries& HF::Core::Scheduling::Weekly::Server< _Entries >::entries ( ) const

inlinevirtual

Get a reference to the current object implementing the persistence API, for the device information.

Returns

reference to the current object for the persistence API.

Implements HF::Core::Scheduling::Weekly::IServer.

Definition at line 525 of file weekly_scheduling.h.

               {
                  return const_cast<_Entries &>(_entries);
               }

---

The documentation for this struct was generated from the following file:

• weekly_scheduling.h
