HF::Transport::Link Struct Reference

This interface represents a link on the transport layer, used to send data to the remote end-point. More...

#include <transport.h>

Inheritance diagram for HF::Transport::Link:

Collaboration diagram for HF::Transport::Link:

Public Member Functions
virtual uint16_t	address () const =0
	Get the address of the device this link corresponds to. More...
virtual void	address (uint16_t addr)=0
	Set the address of this link corresponds to. More...
virtual void	send (Common::ByteArray &array)=0
	Send the data in the given ByteArray using the link to the remote end-point. More...
virtual const HF::UID::UID	uid () const =0
	Return the end-point UID associated with this link. More...

Detailed Description

This interface represents a link on the transport layer, used to send data to the remote end-point.

Definition at line 49 of file inc/hanfun/transport.h.

Member Function Documentation

address() [1/2]

virtual uint16_t HF::Transport::Link::address ( ) const

pure virtual

Get the address of the device this link corresponds to.

Returns

the address of the device for this link.

Implemented in HF::Transport::AbstractLink.

address() [2/2]

virtual void HF::Transport::Link::address ( uint16_t  addr )

pure virtual

Set the address of this link corresponds to.

Parameters

[in]

addr

the address value to set.

Implemented in HF::Transport::AbstractLink.

send()

virtual void HF::Transport::Link::send ( Common::ByteArray &  array )

pure virtual

Send the data in the given ByteArray using the link to the remote end-point.

Parameters

[in]

array

reference to the ByteArray containing the data to send.

Implemented in HF::Application::Link.

uid()

virtual const HF::UID::UID HF::Transport::Link::uid ( ) const

pure virtual

Return the end-point UID associated with this link.

For example, for a ULE transport layer this would return the RFPI/IPUI of the remote device.

Returns

the UID of the remote device of this link.

Implemented in HF::Transport::AbstractLink.

---

The documentation for this struct was generated from the following file:

• inc/hanfun/transport.h
