HAN-FUN API
1.5.3
This project provides the common implementation of ULE Alliance's HAN-FUN application protocol.
|
Saturation Transition. More...
#include <colour_control.h>
Public Member Functions | |
Saturation_Transition (IServer &_server, uint16_t period, int32_t step=0, uint16_t n_steps=0, uint16_t end=0) | |
Constructor. More... | |
Saturation_Transition ()=default | |
Default constructor. | |
~Saturation_Transition () | |
Empty destructor. | |
bool | run (uint16_t time) |
Run the transition. More... | |
bool | next () |
Check if the transition should continue. More... | |
![]() | |
ITransition (IServer &_server, uint16_t period) | |
Constructor. More... | |
Data Fields | |
int32_t | step |
Hue or Saturation step. | |
uint16_t | n_steps |
Counter for the steps needed. More... | |
uint16_t | end |
End value to stop the iteration. More... | |
![]() | |
IServer & | server |
The server instance. | |
uint16_t | period |
Time period for the transition (in 100 msec units). More... | |
uint16_t | remaining_time |
Remaining time until the transition is ran. More... | |
Saturation Transition.
Definition at line 1011 of file colour_control.h.
|
inline |
Constructor.
[in] | _server | server instance |
[in] | period | the Transition period. In units of 100msec. |
[in] | step | the step size for each transition iteration. |
[in] | n_steps | number of steps. |
[in] | end | end value for the transition. |
Definition at line 1026 of file colour_control.h.
|
inlinevirtual |
Check if the transition should continue.
true | the transition continues. |
false | the transition ended. |
Implements HF::Interfaces::ColourControl::ITransition.
Definition at line 1041 of file colour_control.h.
References HF::Interfaces::ColourControl::ITransition::period.
|
virtual |
Run the transition.
This will update the remaining time and check if the transition should run.
[in] | time | time elapsed time since the last call. |
true | run the transition specialization. |
false | don't run the transition specialization. |
Reimplemented from HF::Interfaces::ColourControl::ITransition.
uint16_t HF::Interfaces::ColourControl::Saturation_Transition::end |
End value to stop the iteration.
Definition at line 1015 of file colour_control.h.
uint16_t HF::Interfaces::ColourControl::Saturation_Transition::n_steps |
Counter for the steps needed.
Definition at line 1014 of file colour_control.h.
